SOUNDPROOFING CABINET

This sound-proof cabinet, suitable to reduce the noise caused by ultrasonic welding machines, has the following characteristics:

  • Structure made with anodized aluminum profile 45×45 mm with shelf to hold the ultrasonic generator
  • Welder’s supporting surface  in aluminum
  • Front door to access internal cabinet equipped by transparent mobile protection. The handling of this
    protection is pneumatic. The opening of the mobile protection is 400 mm.
  • Interior light for lighting the working area
  • Right and left side doors for access inside the cabinet and equipped with handles with lock
  • Inner lining made of foam based on melamine resin TECNOCELL FR
  • External walls in gray stratified laminate 4 mm. thickness
  • Electric panel and pneumatic system

Technical features

  • Dimensions 1000x1000x2265 mm.
  • Power supply 230 V – 50 Hz
  • Compressed air supply 6 bar
  • Opening transparent mobile protection 400 mm.

Main Technical features Tecnocell resin:

  • Anthracite color
  • Density 30 kg/m3
    – Useful range of temperature -40° C – + 110° C
    – Decomposition temperature > 180° C
    – No. of cells/inch (PPI) > 50
    – Sound absorption according to ASTM E 1050-86
