NEW US 400 GENERATORS

NEW Portable ultrasound generator series US 400 of the last generation,  designed and manufactured for welding parts made of plastic material.
This fully digital generator makes it possible to undertake all the operations that were previously only possible in generators of a higher price range.
These US 400 generators are complete with backlit display. The innovative programming system uses a rotary switch with selection and enter button.

The dimensions have been reduced thanks to a new electronic layout, with all the components fixed on the PCB. In this way, the internal wiring has practically disappeared to the advantage of the assembling and to the response speed of the entire electronic circuit.
The new US 400 has brilliant performance and fast execution responses.

This means that all the calibration operations are available with a single knob. This generator is unique, thanks to the simplicity of use, the functions available and the very limited cost.

The US 400 generator is also available as an independent unit, without metal case.
The generator unit can therefore be placed inside an electric panel and the display positioned in an accessibel location.
This version is particularly used in the construction of special ultrasound welding machines for small sized parts.

Technical features

  • Power 400 Watt
  • Frequency 20 – 36 – 40 KHz
  • Supply voltage 230V 50 Hz
  • Amplitude setting 50 – 100%
  • Time setting
  • Power setting
  • Frequency control function
  • Piece-counter function
  • Overload circuit
  • Overall dimensions 210 x 70 x 220 mm
